Extend your system LF all the way down! The LSR310S subwoofer incorporates
JBLís patented Slip Streamô Port working in concert with a custom 10"
down-firing driver and a 200 Watt amplifier to add deep, powerful bass to any
studio monitor system. A JBL first, the XLF Extended Low Frequency setting lets
you hear your tracks with the augmented bass tuning used in todayís dance clubs.
- JBL Patented Slip Streamô Port
This patented JBL port
design works in concert with the LSR310S low frequency driver for deep,
dynamic bass response at all playback levels. The double-flared shape of
the port is precisely calculated to optimize low-frequency extension.
- XLF Extended Low Frequency Setting
A JBL first, the XLF
setting activates a specially-engineered tuning that emulates the ample
bass tuning used in today's dance clubs. When producing a dance track,
the XLF setting will inspire you and bring a bit of the club to your
control from. For inspiration to the max, position the LSR310S in the
nearest corner of your room and activate the XLF setting.
- Custom 10" Down-Firing High Excursion Low Frequency Driver
JBL Transducers are legendary for their performance. The custom-designed
driver in the LSR310S exemplifies JBL engineering prowess, delivering
deep low frequency response into the 20 Hz region, and 113 dB peak
output, for long periods at full rated power with no risk of failure.
- Professional Balanced Inputs and Outputs
with balanced XLR
and 1/4" inputs and XLR outpus you can add the LSR310S to any studio
monitor system to extend its low frequency performance or use it as the
".1" LFE Channel in a surround sound system.
- Selectable Input Sensitivity
The -10dBV/+4 dBu sensitivity
switch ensures compatibility with a broad range of signal sources,
allowing you to connect the LSR310S to high-output professional
equipment without any danger of input overload.
- Three Crossover Settings
The 80 Hz setting is recommended
for use with the LSR305, LSR308 or any studio monitors. The External
setting allows use of an outboard crossover.
- Volume Control
Simple and effective, the LSR310S volume
control has detents that make it easy to balance the LSR310S in your
studio monitor system
- Driver : 250mm (10-inch) High-Excursion, Down-Firing
- Low Frequency Extension : 27 Hz
- Max Peak SPL : 113 dB
- Amplifier Power : 200 W CLass D
- Crossover Settings : 80 Hz, XLF, External
- Inputs : 2 x XLR, 2 x TRS Balanced
- Outputs : 2 x XLR
- Maximum Peak Input Level : +20.3 dBu
- AC Voltage : 100-240 VAC +/- 10% 50/60 Hz
- Dimensions (HxWxD):
- 448 mm x 381 mm x 398 mm
- 17.65 in x 15 in x 15.65 in
- Weight : 15.6 kg / 34.3 lbs
